Pneumatic Distribution Block 4 x 1/4 BSP

Distribution block 4 x 1/4 BSP (CPL-303A-1-4)

Pneumatic distribution block with 4 inlets/outlets.
All 4 openings are 1/4 BSP internal.
The block has mounting holes on two sides with a diameter of Ø 5.5 mm

The internal thread is 1/4 internal.
The housing of the block is aluminum.

You can connect a pneumatic coupling with 1/4 BSP external thread to this block on four sides.

This distribution block can be used to make multiple branches from an air source to various applications.

Abbreviations:
BSP: British Standard Pipe, also called Gas thread.

More information about hose sizes and threads can be found here: About Threads
