Lanyard valve for 6mm tube

Pull valve for 6mm hose

Pull valve suitable for 6mm tube, or can be screwed directly into a 1/8 BSP (F) inlet.
Supplied with pull cord and compression fitting for 6mm tube.
With the compression fitting, the valve can be connected to 6mm at both the input and output.
Options for connecting 8mm tube are possible.

The housing of the valve is brass.

You can therefore connect the valve to a pneumatic system that uses a 6mm tube. (8mm is possible with additional choices)

Hose can be connected by providing the tube with a sleeve and then clamping it at the ends with the nut.

Height: 85mm
Length: 90mm
Width: 45mm

Cord length: 80 cm

Weight: approx. 230 gr.

Abbreviations / Definitions:
Compression coupling: System that secures the hose by turning this clamp with a nut.
6mm tube: Outside size of the tube is 6 millimeters.
8mm tube: Outside size of the tube is 8 millimeters:
BSPP: British Standard Pipe Parallel, also called Gas Wire. (Parallel = straight)
(F): Female, female thread. Internal thread.



More information about hose sizes and threads can be found here: About Threads
