6mm-1/8 BSPP straight coupling

6mm-1/8 BSPP Einsteckverbindung gerade
6mm-1/8 BSPP straight coupling
Straight coupling PTC for 6 millimeter tube to 1/8 BSP P

Product number

CPL-951M-6-1/8

Default delivery time

2-4 Work Days

€ 3,50
Price per unit
Quantity:
Order


6mm-1/8 BSPP straight coupling


Straight push-in coupling for 6 millimeter tube with O-ring.
With PTC connection for 6 mm air tube and 1/8 BSP male thread with O-ring.

The male thread is straight and equipped with a sealing ring.
The housing of the coupling is nickel-plated brass.

You can therefore turn the coupling into a 1/8 BSP inlet and connect a 6 millimeter tube to it.

This coupling can be easily used by pushing the air tube into the end of the coupling until it is firmly in place. The tube can be easily removed by pushing the ring back towards the coupling and pulling the hose out.

Abbreviations:

PTC:   Push To Connect.
6mm hose:   External dimension of the tube is 6 millimeters.
BSPP:   British Standard Pipe Parallel, also called Gas thread. (Parallel = straight)
O-ring:   Rubber sealing ring
NBR:   Nitrile rubber

More information about hose sizes and thread can be found here: About Thread
Shape
Straight
Thread (A)
1/8 BSP-P (M)
Tube size
6mm
Tube connection
PTC (Push To Connect)
Material
Brass nickel plated
seal
With O-ring
Max pressure
15 bar
Made in
Germany
