10mm-3/8 BSPT straight coupling

10mm-3/8 BSPT straight coupling
10mm-3/8 BSPT straight coupling
Straight coupling PTC for 10 millimeter tube to 3/8 BSPT (Conical)

Product number

CPL-951M-10-D3/8K

Default delivery time

2-4 Work days

€ 4,60
Price per unit
Quantity:
Order


10mm-3/8 BSPT straight coupling


Straight push-in coupling for 10 millimeter tube.
With PTC connection for 10 mm air tube and 3/8 BSPT male thread.

The male thread is conical and fitted with tape.
The housing of the coupling is nickel-plated brass.

You can therefore turn the coupling into a 3/8 BSP inlet and connect an 10 millimeter air tube to it.

This coupling can be easily used by pushing the tube into the end of the coupling until it is firmly in place. The tube can be easily removed by pushing the ring back towards the coupling and pulling the tube out.

Abbreviations:

PTC: Push To Connect.
10mm air tube: External dimension of the tube is 10 millimeters.
BSPT: British Standard Pipe Taper, also called Gas thread. (Taper = conical)
Conical: Tapered, or tapered.

More information about hose sizes and threads can be found here: About Threads
Shape
Straight
Thread (A)
3/8 BSP-T (M)
Tube size
10mm
Tube connection
PTC (Push To Connect)
Material
Brass nickel plated
seal
With insulating tape
Max pressure
15 bar
Made in
Germany
